AUTOMATIC WRAP REEL

  • Wrap Reel (10 leas)10 Stations Motorized Wrap reel to produce Leas (skeins) of yarn for Count or Strength Testing with 1 meter or 54” collapsible swift.
  • Digital Presettable Counter.
  • Supplied with Yarn Package Stand and Pre-tension device.
  • Technical Specifications: Swift Parameter Metric 1 Meter, Imperial 1.5 yard Swift made of Hard Chrome Palted Steel No. of Leas made at a time 12 Spread of each Lea 20 mm Speed of Traverse One traverse in 16 turns Pre-se Counter Digital Operating Speed 150 RPM Gear Motor 220 Volt Single Phase AC Yarn Guide Chrome Plated, Pig Tail Type Maximum diameter of package 100 mm or as per customer requirement Maximum length of yarn package 250 Package base plate Metallic with powder coated paint. Related Standards: • BS 2010 • ISO 2060 • DIN 53830

    • Features

    • High operational fluency
    • Compact design
    • At par with industry standards

    CONTROL & SYSTEM TENSILE STRENGTH TESTER

  • Overload Protection Protects a force gauge against. The user programs the desired percentage of full scale of the gauge.
  • Auto-return The crosshead moves to a limit switch, force (requires a Series BG force gauge), or travel position stops, and reverses direction at full speed to the other limit switch, force, or travel position.
  • Programmable Button Functions Expands UP and DOWN button operation to three user-configurable modes:
  • Maintained (standard): a short push produces continuous motion until STOP is pressed
  • Momentary: crosshead moves only while the button is pressed
  • Auto: short push produces maintained motion, while holding the button down will produce momentary motion
  • Independent Up and Down Speeds Configurable speeds for up and down directions
  • Speed Extended Range Extends the speed range to 0.5 – 330 mm/min

    • Features

    • LCD display with UP, DOWN, STOP, and emergency stop buttons and soft keys
    • Selectable speed units of measurement (mm/min & in/min)
    • Password protection of test parameters, to prevent unauthorized changes
    • Integrated travel limit switches
    • Removable fixture mounting plate with matrix of threaded holes
    • Stepper motor-driven, produces 0% speed variation with load
    • Mounting holes for bench mounting
    • Unique mechanical design significantly reduces column bending
